Volume 2, Issue 3
Fall 2010


In This Issue:

EDITOR’S NOTE

  • NEW Catalog

PRODUCT FOCUS

APPLICATION INSIGHT

NOSHOK NEWS

TECH TIP

CUSTOMER CONNECTION

NEW LITERATURE

Pressure Measurement Solutions Catalog

Pressure Measurement Solutions Catalog

Whatever your pressure measurement application, you’ll find the solution in our new Pressure Measurement Solutions catalog. This catalog is a comprehensive guide to all of our pressure gauges, options and accessories -  all in one easy to navigate format.

This catalog showcases our 100-900 Series dial indicating pressure gauges, along with our 1000 Series digital gauge and complete lines of  differential and sanitary gauges. Also featured are our full range of diaphragm seals, gauge options, and accessories including pigtail steam syphons, piston-type and sintered snubbers, flanges, maximum indicating pointers, swivel adapter, filling options and more!

Product information is easily accessible; with specifications, ordering information, part number construction examples, and product dimensions provided in clear, easy-to-read format. Gauge options and accessories charts by gauge series, as well as accuracy/standard dial configuration charts are also provided for quick and simple reference.

Click the links under the photo to download a PDF, or order a catalog.

As always, thank you for your support of NOSHOK!

Sheryl Pritt
Editor & Marketing Specialist

  Product Focus

APPLICATIONS

  • GAS PRESSURE MEASUREMENT

  • OIL DRILLING PLATFORMS/
    PIPELINE

  • REFINERIES/
    PETROCHEMICAL INDUSTRY

  • BOREHOLE MONITORING

NEW:

ATEX Approved Explosion Proof Pressure Transducers

Our new 619 and 620 Series heavy-duty pressure transmitters feature a pressure-tight encapsulated design, and are ATEX II 2 G Ex d II C approved. Available in a wide variety of pressure ranges, they are ideal for use in volatile environments such as oil & gas, petrochemical and borehole applications.

These transmitters feature corrosion-resistant stainless steel construction, and a welded pressure connection and measuring cell for exceptional shock and vibration resistance. Their standard output signal is 4-20 mA, 2-wire, however other options are available with voltage outputs in a 3-wire system. The 619 Series transmitter features a 1/2” NPT standard connection, while the front flush 620 Series version eliminates extra space in which the measuring medium can crystallize or form residue.

NOSHOK 619 and 620 Series transmitters incorporate significant levels of RFI, EMI and ESD protection.

  • For dynamic and static measurements
  • High accuracy and long term stability
  • Excellent overload protection
  • Wide variety of pressure ranges
  • Corrosion-resistant stainless steel design
  • Excellent repeatability

[Top of Page]









  • EXCELLENT CORROSION RESISTANCE

  • IDEAL FOR INDUSTRIAL APPLICATIONS

  • WEEE & ROHS COMPLIANT

UPDATE:

Carbon Steel Valves Now Standard With Corrosion Resistant Zinc Nickel Plating

All NOSHOK carbon steel needle & manifold valves are now standard with Zinc Nickel Plating — an ideal choice for harsh environments where corrosion resistance is a necessity.

Improvements in corrosion protection have become increasingly important for outdoor applications, where traditional platings have limited performance capabilities
in demanding environments. In addition to its excellent corrosion resistance (higher than any other sacrificial alloy), Zinc Nickel plating  provides increased deposit hardness which results in extended wear resistance and longer service life, which is ideal for most industrial applications. It is also WEEE and RoHS compliant.

Note: Colors may vary due to normal process variation and will not affect the performance of the valve.

[Top of Page]

Application Insight


MEASUREMENT SOLUTIONS FOR OIL & GAS APPLICATIONS



FOR ORDERING INFORMATION AND SPECIFICATIONS ON
THESE TRANSMITTERS CLICK HERE

FOR INFORMATION ON HOW TO CHOOSE THE CORRECT HAZARDOUS LOCATION PRESSURE TRANSMITTER FOR
YOUR APPLICATION
CLICK HERE



Hazardous Locations Approved Transmitters

FM, CE, CSA, Ex Logos
NOSHOK offers Explosion Proof, Non-Incendive, Intrinsically Safe and Intrinsically Safe Submersible Liquid Level Pressure Transmitters, designed to provide maximum stability and reliability.

In hazardous Oil Field, Pipeline Gas Compressor, Chemical/Petrochemical and Offshore environments, engineers cannot afford to take a chance on faulty or inaccurate measurement instrumentation. NOSHOK’s durable transmitters are the best quality, most reliable sensors available, and are backed by our exclusive 3-year warranty.



                 Hazardous Location Approved Transducers



[Top of Page]

Additional Measurement Solutions Ideal For Oil & Gas Applications

Instrument GroupingCLICK LINKS FOR MORE INFORMATION

Process Gauges
Stainless Steel Liquid Filled Gauges
Digital Gauges
Bimetal Thermometers and Thermowells
Swivel Adapter
Needle Valves
3-Valve Differential Pressure Manifolds
5-Valve Natural Gas Manifolds



NOSHOK NEWS



NOSHOK WINS EXCELLENCE IN EXPORTING AWARD FOR THE 3RD TIME.

THE EXCELLENCE IN EXPORTING AWARD EXEMPLIFIES OHIO'S COMMITMENT TO INTERNATIONAL TRADE.

NOSHOK Receives Excellence in Exporting Award

Lisa Patt-McDaniel, Director of the Ohio Department of Development; and Richard L. Moore, Grand Commodore, Association of Ohio Commodores presented the award to NOSHOK President Jeff Scott, and
Export Sales Manager Latin America. Alejandro E. Utrera.
Lisa Patt-McDaniel, Director of the Ohio Department of Development; and Richard L. Moore, Grand Commodore, Association of Ohio Commodores presented the award to NOSHOK President Jeff Scott, and Export Sales Manager Latin America. Alejandro E. Utrera.

NOSHOK is proud to have been awarded the Governor’s Excellence in Exporting Award from the Ohio Department of Development.  In the past three years, NOSHOK, Inc. has added over 27 new international distributors, and is currently present in major world markets  including Canada, Mexico, Central and South America, Australia and Asia.

The award was presented to NOSHOK at the 3rd Annual Ohio Global Summit, held on Wednesday, September 22, in Columbus, Ohio by the Ohio Department of Development’s Global Markets Division in conjunction with the Association of Ohio Commodores. Since 1986, this prestigious award has been given to select Ohio-based companies and organizations that have achieved success and superior performance in exporting and shown commitment to international trade.

“This award underscores our ongoing commitment to offer high quality products and excellent support to our distribution partners worldwide. We will continue to pursue growth in domestic and international markets, while being at the forefront of industrial instrumentation,” states Alejandro Utrera, NOSHOK’s Export Sales Manager, Latin America.

NOSHOK thanks our loyal customers and distributors for their ongoing support, as well as the Ohio Department of Development for this honor.

[Top of Page]



UNIQUE SEAL SIGNIFICANTLY INCREASES PRESSURE RATING WITHOUT COMPROMISING FLOW.

NOSHOK Awarded Patent For Innovative Valve Design

NOSHOK ValvesNOSHOK newly patented valve design features a unique body-to-bonnet metal-to-metal seal that significantly increases the pressure rating of the valve without compromising the flow. This design also helps to maintain the integrity of the bonnet threads by segregating them from the process media.  (Patent No. US 7,758,014 B2)

The body seal incorporates a dovetail undercut below the seal that improves the metal-to-metal contact forces as pressures increase, as well as a dual outlet orifice to maximize fluid flow. These unique design features increase the pressure limits of the valve to 10,000 psi on hard seat, which is significantly higher than similar-sized miniature needle valves.

[Top of Page]

Background:

*
Native Houstonian, 28 years experience as a sales professional in the instrumentation, process control and measurement industry
*
Undergraduate degree University of Houston; MBA Our Lady of the Lakes San Antonio
*
Member of Delta Mu Delta National Honor Society recognizing academic excellence in business studies
*
1/2 of career in distribution & other 1/2 in sales on the manufacturing side
*
A valued employee at NOSHOK for 9-1/2 years



Employee Spotlight:
Stan Wright, National Sales Manager

Stan Wright, National Sales ManagerGreatest Personal Accomplishment:
“My greatest personal accomplishment is being a good husband and father. It’s very gratifying to see your kids grow into responsible adults. The conversations that we have really blow me away; from politics to business to developing interpersonal skills & working with people. Good ideas and strong opinions really fly across the table.”

Greatest Business Accomplishment:
“Increasing sales revenue is always important. But the real thrill is helping co-workers develop their own skills and then observe the results and successes. It is also very gratifying to be a part of working jointly with our distribution partners, and to witness success with their customer base. Helping our distributors grow profitably while providing real value to our customers is what makes working with NOSHOK a lot of fun.”

[Top of Page]



NOSHOK TEAM UNDEFEATED

NOSHOK NCIFC THANKS OUR SPONSORS FOR THEIR SUPPORT!

NOSHOK Soccer Team Wins 4th SCORES Championship

NOSHOK Soccer TeamThe NOSHOK Coed International FC competed in its final tournament of the season with a championship in the America SCORES Summer Cup at CSU’s Krenzler Field on July 31st.  The team went undefeated on the day making this the fourth SCORES championship since 2008.  Overall, NCIFC was 19-3 and won four tournament championships in 2010 and improves the team record to 52-9-3.

NCIFC would like to thanks it’s corporate sponsors for their ongoing support! The NOSHOK team is sponsored by Morgan Stanley, Global Technical Recruiters, Frontline Soccer Shop, Adecco, and C.H. Robinson International Inc., and NOSHOK, Inc.

Watch the NOSHOK Coed Int’l FC SCORES Summer 2010 Cup Highlights on YouTube.

Sponsor Logos

[Top of Page]

  Tech Tip

Q: What applications require the various lens materials, and to what maximum temperature can each be subjected?
A: Lens materials include Instrument Glass, Laminated Safety Glass, Tempered Glass, and plastic. Glass lenses are used for abrasion, chemical and wear resistant properties. Laminated safety glass reduces the possibility of shattering if broken.  Tempered glass is 2 to 5 times stronger the plain glass.  Plastic lenses are used for impact, corrosion and chemical resistance.  Special attention should be paid to the temperature and corrosive environments.  Polycarbonate is selected for its superior impact resistance, Plexiglass for its clarity and scratch resistance and Homalite for is superior chemical resistance.  In general, gauges with plastic lenses should remain below 140°F.
[Top of Page]
  Customer Connection

FOR INDUSTRY AND COMPANY NEWS AND UPDATES, SIGN UP TO FOLLOW US ON FACEBOOK, TWITTER & LINKED IN, AND SUBSCRIBE TO OUR RSS FEEDS!

Promotional80% Savings On Heavy Duty OEM Transducers

SAVE UP TO 80% on our Heavy Duty OEM Transducers for a limited time only, while products last.

NOSHOK 600 Series Heavy Duty OEM Transducers utilize advanced sputtered thin film sensor technology to produce a highly accurate and stable pressure transducer for the high volume OEM. CE compliant. RFI, EMI and ESD protection.

These promotional prices are available only on orders placed through this web page from October 1 to October 31st, 2010.

Click HERE for details.

[Top of Page]

ISO Logo
For more information on NOSHOK products, please visit our website at www.noshok.com
Contact: Sheryl Pritt, Mktg. Specialist, 1010 West Bagley Road, Berea, Ohio 44017
440-243-0888 x220, spritt@noshok.com
