NOSHOK The Pointer
Volume 1, Issue 4
Fall 2009

In This Issue:

EDITOR’S NOTE

PRODUCT FOCUS

APPLICATION INSIGHT

NOSHOK NEWS

TECH TIP

CUSTOMER CONNECTION

IDEAL FOR DEMANDING
APPLICATIONS

RESISTANT TO
VIBRATION &
PULSATION

NOSHOK Expands Its Presence In The
Latin American Market

Alejandro E. Utrera, Export Sales Manager

To improve communication and better accommodate the needs of our valued Latin American Distributors & Customers, we are pleased to announce the addition of Alejandro E. Utrera to our team as the new Export Sales Manager for Latin America.

Alejandro is fluent in both English and Spanish, and will provide sales support to our Distributors & Customers throughout Central and South America and the Caribbean, as well as focusing on expanding NOSHOK’s presence in those markets.

Alejandro joined the NOSHOK team in February 2009, and has been through extensive training in each department of the company. This hands-on training has given him an in-depth knowledge of NOSHOK’s products and services, allowing him to provide support not only in sales, but also in customer service and technical training for all of our Latin American Distributors & Customers. Alejandro may be reached at our main offices at:

NOSHOK, Inc.
1010 West Bagley Road  Berea, OH 44017
Phone: 440-243-0888, ext. 223   Fax: 440-243-3472
E-mail: autrera@noshok.com

Please join us in welcoming Alejandro to our team!!

PRODUCT FOCUS

The Trouble Shooter

300 Gauge with MIP

The NOSHOK 300 Series Brass Case liquid filled gauges are high quality, reliable gauges designed for durability, accuracy and long life. These gauges are available with an optional Maximum Indicating Pointer—an invaluable tool for performing system set-up and diagnostics.

  • Pressure ranges through 15,000 psi
  • Their heavy one-piece die casting integrates all components into a solid unit to eliminate leakage
  • Glycerine fill greatly reduces the effects of vibration, pulsation and shock
  • Maximum Indicating Pointer is easily reset with a knurled thumb screw

[Top of Page]





IDEAL FOR APPLICATIONS
iNCLUDING:

  • Water & Waste Water
  • Chemical Tanks
  • Methane wells
  • Marine Applications

3 YEAR WARRANTY

Intrinsically Safe Submersible Liquid Level Transmitters
For Hazardous Locations

Our robust 627 Series Intrinsically Safe Liquid Level Transmitters have an accuracy to ±0.25% Full Scale (Best Fit Straight Line); ±0.125% Full Scale for 4 psi and above only. Utilizing advanced diffused semi-conductor technology and a sputtered thin film sensor, they deliver maximum stability and reliability.

  • Ranges from 0 inH2O to 50 inH2O through 0 psi to 350 psi
  • Welded 316 stainless steel pressure chamber
  • CE compliant to suppress RFI, EMI, and ESD
  • Factory Mutual and Canadian Standards Association approved
  • Standard cable is Polyurethane; Teflon® cable optional

[Top of Page]







HIGHLY RELIABLE,
ACCURATE &
ECONOMICAL


High Accuracy, Cost Effective Temperature Measurement

NOSHOK offers a full line of mechanical and electronic temperature measurement solutions designed to easily integrate into a variety of applications.  Visit our website at www.noshok.com for more information on these products.

High Accuracy, Cost Effective Temperature Measurement
  • Industrial and Instrument Type Bimetal Thermometers are high quality, accurate and cost effective; available in several sizes ranges, and connection options
  • Vapor Actuated Remote Thermometers indicate media temperature using a temperature-actuated liquid in the sensing element and a highly accurate, high quality pressure gauge
  • 800 Series Platinum Resistance Temperature Transmitters provide reliability, stability and a quick response time at an economical price—also available with our 1800 Series Attachable Loop Indicator
  • 850 Series Electronic Indicating Temperature Switch/Transmitter utilizes PT100 technology to provide continuous temperature monitoring, electronic temperature switching, and transmission of analog output of 4-20 mA, while providing local digital indication





[Top of Page]





REDUCES THE POSSIBILITY
OF DAMAGE TO THE
INSTRUMENT

PROVIDES
OPERATOR PROTECTION

An Investment In Safety

Thermowells

NOSHOK Thermowells are recommended wherever the process being measured is under pressure, corrosive, abrasive, or moving at a high velocity to reduce the possibility of damage to the temperature instrument and provide operator protection and safety.

  • Allows a temperature instrument to be removed and replaced without shutting down and possibly draining the process
  • 1/2 inch NPSM instrument connection, 3/4 inch process connection standard

[Top of Page]


APPLICATION INSIGHT


Force Measurement Solutions

IDEAL FOR APPLICATIONS
INCLUDING:

  • Cable or rod tension
  • Weight measurement
  • Overload protection
  • Clamp force
  • Fill level measurement
Welding
Conveyor Belt
Bridge
NOSHOK Series 3540 tension and compression force transducers are available in a multitude of sizes and shapes to fit almost any application, including:·
  • Manufacturing automation
  • Cable supports for bridges or high tension lines
  • Crane hoisting
  • Chain hoists
  • Conveyer belts
  • Welding machinery
  • Towing

A 316 stainless steel construction on many versions provides corrosion resistance and durability, making them ideal for harsh environments. Measuring ranges from 0 to 5 kN through 0 to 5000 kN are standard, with full scale accuracy ranging from ±2.0% (BFSL) to ±0.04%, depending on the particular version.

Several amplified or unamplified outputs are available to interface with most electrical systems. They offer high shock and vibration resistance and small temperature drift.



[Top of Page]

Seires 3540 Tension and Compression Force Transducer



IDEAL FOR APPLICATIONS
INCLUDING:

  • Hoists
  • Weighing
  • Factory Automation
Robotic Automation
Screen Printing
Cable-hoist



NOSHOK Series 2351 S-Type tension and compression force transducers are easily installed, and suitable for dynamic or static measurements in applications such as:

  • Heavy-duty construction
  • Cranes
  • Cable hoists
  • Platform hoists
  • Magnetic lifts
  • Lifting & leveling systems
  • Screen/offset printing machines
  • Conveyor belts
  • Robotic automation
  • Sheet metal fabrication

A conventional configuration provides internal threads to allow force to be easily introduced via suitable swivel heads. A connector plug is on the broad side of the body, and a cable socket is angled so that cable runs parallel to the direction of force, providing space-savings and a protected installation. A special version with integrated overload protection and a selectable measuring range is also available and is intended for applications in measurement engineering.

Factory internal calibrations are performed in tension and compression — 4 to 20 mA and 0 to10 V, with a zero signal of about 12 mA and 5 V, respectively. An optional EPE01 programming unit allows selecting any of three different measuring ranges (100%, 50%, and 30%) without having to remove the force transducer. Overload protection is rated for 250% of the maximum nominal load.

[Top of Page]

NOSHOK Series 2351 S-Type tension and compression force transducer


NOSHOK NEWS





Return Materials Authorization (RMA) Request Form Available
On Website

RMA Form

A new RMA Request Form is available on our website. Product returned to NOSHOK for any reason must have a NOSHOK issued Return Material Authorization (RMA) number.

Upon submission of the completed RMA Request form, we will review your request and, if accepted, will email you the Return Material Authorization (RMA) Acknowledgement. The RMA number found on the acknowledgement must be clearly visible on the outside of the package. The RMA Acknowledgement must also be included with the package showing the RMA number, part number, quantity, and reason for return.
For more information on our Return Material Authorization Policy, click here.

[Top of Page]




NOSHOK Takes A Stand Against Terrorism

C-TPAT Logo

The U.S. Customs and Border Protection (CBP) recently certified NOSHOK as a partner in the Customs-Trade Partnership Against Terrorism (C-TPAT). Through our partnership with CBP, NOSHOK underscores our commitment to help secure our country’s borders, and ensure the continued free flow of international trade.

C-TPAT is a government-business initiative designed to build cooperative relationships that reinforce and improve international supply chain and U.S. border security. By participating in C-TPAT, NOSHOK will establish a more secure and efficient supply chain for our employees, suppliers and customers. We will have a commitment to both trade security and trade compliance established in our business practices. CBP will work with us closely to ensure our supply chain security and compliance with trade laws. For more information on C-TPAT, contact Industry Partnership Programs at (202) 344-1180 or fax (202) 344-2626 or email them.




Link Request

Link to NOSHOK, Inc.

We’re asking all of our distributors and customers to add a link on your website, to our website at www.noshok.com. We appreciate your support!




NOSHOK Goes Global

Global Spec the Engineering Search Engine

We now have an expanded presence in the online search directory Global Spec. Our profile page can be viewed here.

Our presence on this site will reach a high number of qualified potential customers, and includes company information, press announcements, and fully searchable specifications for all of our products.

Global Spec is a search engine and information resource for the engineering, industrial and technical communities. The site has a global user base of more than 5,200,000 registered users; that continues to grow by more than 80,000 new registrants each month.


TECH TIP





TIPS TO HELP AVOID WORST
CASE ERRORS WHEN USING
DIAPHRAGM SEALS

Diaphragm Seal Thermal Error Calculations

Diaphragm Seals Thermal Error Calculations

A new NOSHOK Engineering Bulletin is now available on our website.

This reference document was designed to help predict “worst case” errors when diaphragm seals are applied to both gauge pressure and differential pressure instruments. The document contains valuable information on best practices for minimizing errors with the usage of the Type 10, 25, 25H and 30 Diaphragm Seals, including equations, fill fluid expansion factors, and diaphragm spring rates and volumes.

Click here for other valuable reference tools and links that are also available on our website.



[Top of Page]


CUSTOMER CONNECTION





EVERYONE WHO
SENDS THEIR
FEEDBACK OR
TESTIMONIAL
WILL BE ENTERED
TO WIN

What's Your Story?
Tell Us And You Could Win A $100 VISA Gift Card!

As our valued customer/distributor, you are the main focus of our business. We need your feedback to help us serve you even better. Win a VISA Gift Card

We’re asking you to email us with your thoughts on our company, and your experiences with our products. Tell us how our products provided a solution in your specific application. Give us your comments, or suggestions for improvement. If you have videos or photos of our products in your application, we’d like to see those as well.

Please email your feedback to spritt@noshok.com, and include your name, title and company name. If you are willing to have your feedback, testimonial, photos, and/or video featured in any of our printed or online marketing materials, which may also be published in industry publications, please indicate your consent in the email.

Everyone who sends us their feedback/testimonial will be entered in a drawing to win a $100 VISA Gift Card! The drawing for the VISA Gift Card will be held on December 1, 2009.

Winner of NIKON Coolpix S230 10-Megapixel Touch Screen Digital Camera

We are happy to announce Jason Pittman from Control Plus, Inc. is the winner of our NIKON Coolpix digital camera drawing, for completing our customer survey announced in the previous Pointer. Congratulations, Jason!

[Top of Page]

ISO LogoFor more information on NOSHOK products, please visit our website at www.noshok.com
Contact: Sheryl Pritt, Mktg. Specialist, 1010 West Bagley Road, Berea, Ohio 44017
440-243-0888 x220, spritt@noshok.com
